For all clear, non-diphasic liquids and for all types of pipes from DN20 to DN1200:

• Accuracy of measurement 1 % F.S.
• Communications : 4~20 mA & RS485 Modbus
• Programmable data logger 16 GB SD card
• 16 hours battery life
• Non-invasive transducers Stainless steel IP68
• Mounting rails for optimal measurement
• 2x TT02 Transducers IP68 DN20 to DN1200
  -40 °C ~ 80°C
• Mounting rails with strip and clamps
• Standard cable length: 5 meters
• Optional energy meter

• For wastewater and two-phase liquids (emulsion)
• Non-intrusive transducers from DN40 to DN4000
• Suitable for all types of pipes (uni-material)
• Transducers -35 ～ 85 ° C
• 5 m cables
• Excellent measurement capacity for low flow rates (from 0.05m / s)
• Easy installation & configuration
• Outputs: 4-20mA as standard
• Accuracy: 0.5% to 2.0%
• Battery: Autonomy 40 h

• Accuracy: 1%
• Non-intrusive transducers
• DN15 to DN6000 ~ depending on type of transducers
• Energy meter option: thermal and cooling energy
• Communication: RS-485 Modbus RTU
• Outputs: 1x 4-20mA ~ 1x 4-20mA ~ 1x Pulse ~ 1x Relay
• Inputs: 3 x 4-20mA
• Integrated data logger: SD card slot
• IP67 flowmeter ~ IP68 transducers
• Compact & Robust
• Dimensions: 13 cm × 15 cm × 8 cm ~ Weight: 1 kg
• 2x High temperature non-intrusive transducers -30 ° C to 160 ° C
• FREE mounting rail with transducers

• Measuring speed: 0.1 to 25 m / s
• Connection distance: 0.3 to 30 meters
• Resolution: 0.1 mm / s
• Measuring precession: ≤2%
• Data update cycle: 1 second
• Outputs & communications: 4-20 Ma x2 wires or x4 wires RS232, RS485 Modbus
• Transmitting frequency: 24 GHz (K-band)
• Communication speed: 115200 (standard)
• Power supply: 12 ~ 24 VDC
• Operating temperature: -35 ~ 70 ° C
• Compact size: 118 x 118 x 60 mm
• Material: Metal composite material
• Protection: IP68
• Options & Possibilities :
• Battery or solar panel power
• Local and / or remote data display
• Data processing: Tables, Curves & Alarms in real time

• For wastewater and two-phase liquids (emulsion)
• Non-intrusive transducers from DN40 to DN4000
• Suitable for all types of pipes (uni-material)
• Transducers -35 ～ 85 ° C
• 5 m cables
• Excellent measurement capacity for low flow rates (from 0.05m / s)
• Easy installation & configuration
• Outputs: 4-20mA as standard
• Accuracy: 0.5% to 2.0%
• Battery: Autonomy 14 h

• Accuracy: ± 1%
• Speed: 0 ~ ± 12 m / s bidirectional
• Display: Large LCD screen 4x16 characters
• Menu in French
• Communication: RS-232, 75-57600 bps
• Built-in recorder: 2000 lines of recording data
• Built-in Ni-MH battery, autonomy 12 hours in operation
• Dimensions: 210 * 90 * 30 mm
• Weight 0.5 kg
• Choose your non-intrusive transducers between DN15 and DN6000
• Mounting rails for transducers -30 to 90 ° C FREE

OFFER VALID UNTIL 31/03/2020

• Accuracy: 1%
• Non-intrusive transducers
• DN20 to DN6000 ~ depending on type of transducers
• Rechargeable battery, Autonomy 50 hours
• Data logger
• Communication: RS-485 Modbus RTU
• Output: 4-20mA
• IP67 flowmeter ~ IP68 transducers
• Compact & Robust
• Dimensions: 270 × 215 × 175 mm ~ Weight: 3 kg
• 2x Non-intrusive transducers -35 ° C to 85 ° C
• Other output (optional): Pulse, Relay
• Energy meter option

• High measurement accuracy: Accuracy: 0.5%
• Wide measuring range: DN15 to DN6000
• Energy meter: Measurement of thermal and cooling energy
• Wide temperature range: Fluid from -30 ° C to 160 ° C
• Multiple communication interface as standard:
• Outputs: RS-485 Modbus RTU ~ 1x 4-20 mA ~ 1x Pulse ~ 1x Relay
• Inputs: 3x 4-20mA (acquisition of temperature, pressure, level signals, etc.)
• Multiple materials and pressures available:
• Carbon steel, 304 stainless steel, 316 stainless steel, 1.0 Mpa, 1.6 Mpa, 2.5 Mpa
• IP68 protection - Fully waterproof: Does not fear splashing water or humid environments
• Waterproof keyboard: 4 keys - settings and multiple functions

• Speed, level, flow and temperature
• New velocity filter for more accurate readings
• Integrated micro data logger
• SDI-12 communications
• LCD display option available

• For wastewater and two-phase liquids (emulsion)
• Non-intrusive transducers from DN40 to DN4000
• Suitable for all types of pipes (uni-material)
• Transducers -35 ～ 85 ° C
• 10 m of cables
• Excellent measurement capacity for low flow rates (from 0.05m / s)
• Easy installation & configuration
• Outputs: 4-20mA as standard
• Accuracy: 0.5% to 2.0%
• Power supply: 100-240VAC or 10 - 28 VDC
