TNRP58 Liquid pulsed radar level transmitter
  • Maximum measurement range: 70m
  • Measuring accuracy: ± 15 mm
  • Process temperature: (-40 ~ 80) ° C (-40 ~ 120) ° C (-40 ~ 250) ° C (-40 ~ 400) ° C
  • Process pressure: Normal, (-0.1 ~ 4) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Process connection: G / H / I / J / K
  • Antenna material: S / T / V
  • Flange accessories: L / M / N / P
  • LCD optional

Add to wishlist

  • Garanties sécurité Garanties sécurité
  • Politique de livraison Politique de livraison
  • Politique retours Politique retours

Multiple patented antennas, anti-dew, anti-crystallization, anti-fixation, anti-dust, centralized beam. Solving the disadvantages of the 6G radar antenna, such as ease of blocking, large size, wide transmission angle, incorrect measurement, short measurement distance, etc.

Application:

Ideal for bulk level measurement and suitable for measuring the measuring range, high dust, high temperature and low dielectric constant in the cement, energy and steel industries.

Maximum measurement range: 70m
Measurement accuracy: ± 15mm

TNRP58

Download

Transmetteur de niveau radar

TNRP 55,56,57,58,59 Transmetteur de niveau radar pulsé liquide

Reviews

No customer reviews for the moment.

Write your review

TNRP58 Liquid pulsed radar level transmitter

  • Maximum measurement range: 70m
  • Measuring accuracy: ± 15 mm
  • Process temperature: (-40 ~ 80) ° C (-40 ~ 120) ° C (-40 ~ 250) ° C (-40 ~ 400) ° C
  • Process pressure: Normal, (-0.1 ~ 4) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Process connection: G / H / I / J / K
  • Antenna material: S / T / V
  • Flange accessories: L / M / N / P
  • LCD optional
