TNRP57 Liquid pulsed radar level transmitter
  • Maximum measuring range: 20m
  • Measuring accuracy: ± 3 mm
  • Process temperature: (-40 ~ 150) ° C
  • Process pressure: Normal, (-0.1 ~ 0.5) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Flange accessories: U
  • LCD optional

Add to wishlist

  • Garanties sécurité Garanties sécurité
  • Politique de livraison Politique de livraison
  • Politique retours Politique retours

The general-purpose 26 GHz pulse radar level transmitter allows continuous level measurement up to 20 m with a 4-20 mA signal output, configured via its integrated push-button display module. The non-contact liquid level sensor is designed for the storage of chemicals or treatment applications in tanks of any material, located above or below ground level. Select this sensor for harsh process conditions with corrosive media, light foam on the surface or agitation, higher temperatures or pressures, condensation or steam and installation in a flange connection. Typical applications include bulk storage and processing tanks.

TNRP57

Download

Transmetteur de niveau radar

TNRP 55,56,57,58,59 Transmetteur de niveau radar pulsé liquide

Reviews

No customer reviews for the moment.

Write your review

TNRP57 Liquid pulsed radar level transmitter

  • Maximum measuring range: 20m
  • Measuring accuracy: ± 3 mm
  • Process temperature: (-40 ~ 150) ° C
  • Process pressure: Normal, (-0.1 ~ 0.5) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Flange accessories: U
  • LCD optional
