TNRP56 Liquid pulsed radar level transmitter
  • Maximum measurement range: 30m
  • Measuring accuracy: ± 3 mm
  • Process temperature: (-40 ~ 80) ° C (-40 ~ 130) ° C (-40 ~ 250) ° C (-40 ~ 400) ° C
  • Process pressure: Normal, (-0.1 ~ 0.3) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Process connection: G / H / I / J / K
  • Antenna material: S / T / V
  • Flange accessories: L / M / N / P
  • LCD optional

Add to wishlist

  • Garanties sécurité Garanties sécurité
  • Politique de livraison Politique de livraison
  • Politique retours Politique retours

The general purpose 26 GHz pulse radar level transmitter allows continuous level measurement up to 30 m with a 4-20 mA signal output. It is configured via its integrated push-button display module. The non-contact liquid level sensor is intended for the storage or treatment of chemicals, petroleum, water, wastewater and diluted chemicals, in tanks of all materials, above or below - below ground level. Select this sensor for difficult process conditions with low or non-corrosive fluids, light foam on the surface or agitation, higher temperature or pressure, condensation or steam and installation in a tank adapter , flange connection or metal support pipe Typical applications include bulk storage, tanker trucks, process tanks, retention and neutralization tanks.

TNRP56

Download

Transmetteur de niveau radar

TNRP 55,56,57,58,59 Transmetteur de niveau radar pulsé liquide

Reviews

No customer reviews for the moment.

Write your review

TNRP56 Liquid pulsed radar level transmitter

  • Maximum measurement range: 30m
  • Measuring accuracy: ± 3 mm
  • Process temperature: (-40 ~ 80) ° C (-40 ~ 130) ° C (-40 ~ 250) ° C (-40 ~ 400) ° C
  • Process pressure: Normal, (-0.1 ~ 0.3) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Process connection: G / H / I / J / K
  • Antenna material: S / T / V
  • Flange accessories: L / M / N / P
  • LCD optional
