TNRP55 Liquid pulsed radar level transmitter
  • Maximum measurement range: 10m; 30m (Horn 80mm)
  • Measurement accuracy: ± 5mm
  • Process temperature: (-40 ~ 130) ° C
  • Process pressure: (-0.1 ~ 0.3) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Process connection: F
  • Antenna material: R
  • Flange accessories: L
  • LCD optional

Add to wishlist

  • Garanties sécurité Garanties sécurité
  • Politique de livraison Politique de livraison
  • Politique retours Politique retours

General use 26 GHz. The pulse radar level transmitter provides continuous level measurement up to 10 m with a 4-20 mA signal output and is configured via its integrated push button display module. The non-contact liquid level sensor is intended for storage applications of chemicals or water in metal or reinforced concrete tanks above ground level or in tanks of any material. Select this sensor for easy application conditions with corrosive products, slight agitation, condensation or steam, and installation in a tank adapter or profiled flange fitting. Typical applications include bulk chemical storage and tankers.

TNRP55

Download

Transmetteur de niveau radar

TNRP 55,56,57,58,59 Transmetteur de niveau radar pulsé liquide

Reviews

No customer reviews for the moment.

Write your review

TNRP55 Liquid pulsed radar level transmitter

  • Maximum measurement range: 10m; 30m (Horn 80mm)
  • Measurement accuracy: ± 5mm
  • Process temperature: (-40 ~ 130) ° C
  • Process pressure: (-0.1 ~ 0.3) MPa
  • Frequency range: 26 GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
  • Process connection: F
  • Antenna material: R
  • Flange accessories: L
  • LCD optional
