TNRP53 Liquid pulsed radar level transmitter
  • Maximum measurement range: 35m
  • Measurement accuracy: ± 10mm
  • Process connection: Flange 316L
  • Antenna material: Stainless Steel 316L / PTFE
  • Process temperature: (-40 ~ 200) ° C
  • Process pressure: (-0.1 ~ 4) MPa
  • Frequency range: 6GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)

Add to wishlist

  • Garanties sécurité Garanties sécurité
  • Politique de livraison Politique de livraison
  • Politique retours Politique retours

The antenna of the radar level instrument transmits a very narrow microwave pulse which propagates at the speed of light in space. When you meet the dielectric surface to be measured, part of its energy is reflected and received by the same antenna. The time interval of the transmit and receive pulses is proportional to the distance between the antenna and the dielectric surface to be measured. Therefore, the distance between the antenna and the dielectric surface to be measured can be calculated.

TNRP53

Download

Transmetteur de niveau radar

TNRP 51,52,53,54 Transmetteur de niveau radar pulsé liquide

Reviews

No customer reviews for the moment.

Write your review

TNRP53 Liquid pulsed radar level transmitter

  • Maximum measurement range: 35m
  • Measurement accuracy: ± 10mm
  • Process connection: Flange 316L
  • Antenna material: Stainless Steel 316L / PTFE
  • Process temperature: (-40 ~ 200) ° C
  • Process pressure: (-0.1 ~ 4) MPa
  • Frequency range: 6GHz
  • Output signal: (4 ~ 20) mA / HART
  • Power: dual-wire (DC24V) four-wire (DC24V / AC220V)
