PPC-D Calibrateur de pression portable Pneumatique &...
- Pneumatic Pressure: -0.85 to 20 bar.
- Hydraulic Pressure: 0 to 400 bar.
- Accuracy: ±0.025% FS.
- Temperature Compensation: Automatic from 0 to 50 °C.
- Selectable Pressure Units: kg/cm², psi, bar, mbar, etc.
- Current Input: 50 mA active, 25 mA passive, 800 Ω resistance.
- Voltage Input: 0 to 30 VDC, resolution 0.01 (mA/V).
- Switch Test: Up to 5 VDC.
- Media: Air and oil.
- Overpressure Alarm: 120% FS (visual and audible).
- Pressure Generation: Built-in pumps with fine adjustment vernier.
- Power Supply: Rechargeable 7.2 Volts (AA) battery.
- Operating Temperature: 15 °C to 40 °C.
- Storage Temperature Range: 10 °C to 60 °C.
- Protection Class: IP10.
- Zero Adjustment: Automatic if pressure is less than 1% FS.
PRCAL 518 Intelligent Process Calibrator
- Generation and measurement of electrical signals
- Generation and measurement of temperatures
- Pulse frequency generation and measurement
- Automatic switch test
- 24 V loop power supply
- RS-232 communication
- Data recording
- Documentation and automated procedures
- Communication Hart
- Intelligent pressure external modules
PPC-D+ Calibrateur de pression portable Pneumatique &...
Pneumatic Pressure: -0.85 to 20 bar.Hydraulic Pressure: 0 to 400 bar.Accuracy: ±0.025% FS.Temperature Compensation: Automatic from 0 to 50 °C.Selectable Pressure Units: kg/cm², psi, bar, mbar, etc.Current Input: 50 mA active, 25 mA passive, 800 Ω resistance.Voltage Input: 0 to 30 VDC, resolution 0.01 (mA/V).Switch Test: Up to 5 VDC.Media: Air and oil.Overpressure Alarm: 120% FS (visual and audible).Pressure Generation: Built-in pumps with fine adjustment vernier.Power Supply: Rechargeable 7.2 Volts (AA) battery.Operating Temperature: 15 °C to 40 °C.Storage Temperature Range: 10 °C to 60 °C.Protection Class: IP10.Zero Adjustment: Automatic if pressure is less than 1% FS.
PPC-H 200 Hydraulic pressure calibrator 0 to 200 Bar ± 0.05%
Models: PPC-H (accuracy 0.05% FS)
Pressure Range: 0 to 200 Bar.Temperature Compensation: 0 °C to 50 °C.
Display: Backlit LCD, 5-digit resolution, multiple units (Pa, Bar, PSI, mmHg, etc.).
Inputs: Current (50 mA active / 25 mA passive), voltage (0-30 VDC), resolution 0.001.
Pressure Generation: Integrated pneumatic/hydraulic pumps with fine adjustment.
Construction: Robust IP10 case, 330 x 235 x 125 mm, 6 kg.
Overpressure Alarm: 120% FS (visual/audible).
Power Supply: Rechargeable battery.
Delivery: Calibrator, adapters, test kit, oil, RS-232, manual.
copy of Calibrateur de pression portable PPC-P (Plage : -0,85...
Pressure range: -0.85 to 2 barPressure measurement and generationAccuracy: ± 0.05% FSTemperature compensation: 0 °C to 50 °CSelectable measurement units:Kg/cm², Bar, mBar, PSI, mH₂O, mmH₂O, cmH₂O, inH₂O, ftH₂O, mmHg, inHg, Atm, MPa, kPa, PaCurrent measurement: Active loop: 50 mA, Passive loop: 25 mA, Load resistance: 800 ΩVoltage measurement: 0 to 30 VDCResolution (mA / V): 0.001Switch test: Maximum 5 VDCMedium: AirOverpressure alarm: Visual and audible, 120% FSPressure generation: Integrated pneumatic pump with fine adjustment vernier and depressurization valvePower supply: Rechargeable 7.2 V AA batteryDimensions / Weight: 330 x 235 x 125 mm, 4 kg
CN-BT Blackbody Calibration Furnace Tem. Ambient +10°C to 300°C
CN-BT (Low Temperature):
- Temperature Range: Ambient Temp. +10 °C to 350 °C
- Accuracy: Less than 0.5% F.S. (Min. 1 °C)
- Stability: ± 0.5 °C
- Resolution: 0.1 °C
- Emissivity: 0.98
- Aperture Diameter: 25 mm
- Time to Reach Max Temperature: 45 minutes
- Stabilization Time: 20 minutes (above 75 °C)
- Dimensions (L x W x H) / Weight: 485 x 430 x 190 mm / 11 kg
- Calibration Certification: Factory with ISO17025 traceability included
PRCAL 517 Multifunction process calibrator
- Generation and measurement of electrical signals
- Generation and measurement of temperatures
- Pulse frequency generation and measurement
- Automatic switch test
- 24 V loop power supply
- RS-232 communication
- Data recording
- Documentation and automated procedures
- Intelligent pressure external modules
PI105 Digital pressure gauge ± 0,05 % - Compound / Vacuum
- Accuracy: ± 0.05% of full scale
- Units: kPa, Pa, PSI, Kg / cm², Bar, MPa
- Display: Large LCD screen with 5 DIGIT dual display
- Keys: On / Off, Reset, backlight
- Connection: 1/4 ’’ NPT, 1/4 ’’ G (or customizable)
- Dial size: 105 mm
- Pressure and temperature display simultaneously
- Max & min pressure recording
- Battery alarm function
- Ease of use, robust design and reliable performance
- Lithium battery 1 year autonomy in 24 hour operation
- Delivered in a storage case
- Calibration certificate with factory traceability
- ISO17025 certificate COFRAC equivalent or NIST optional
PPC-H + 200 Hydraulic pressure calibrator 0 to 200 Bar ± 0.025%
Models: PPC-H + (accuracy 0.025% FS)
Pressure Range: 0 to 200 Bar.Temperature Compensation: 0 °C to 50 °C.
Display: Backlit LCD, 5-digit resolution, multiple units (Pa, Bar, PSI, mmHg, etc.).
Inputs: Current (50 mA active / 25 mA passive), voltage (0-30 VDC), resolution 0.001.
Pressure Generation: Integrated pneumatic/hydraulic pumps with fine adjustment.
Construction: Robust IP10 case, 330 x 235 x 125 mm, 6 kg.
Overpressure Alarm: 120% FS (visual/audible).
Power Supply: Rechargeable battery.
Delivery: Calibrator, adapters, test kit, oil, RS-232, manual.
PPC-P-7 Portable pressure calibrator -0,85 à 7 Bar 0,05% P.E.
Pressure range: -0.85 to 7 barPressure measurement and generationAccuracy: ± 0.05% FSTemperature compensation: 0 °C to 50 °CSelectable measurement units:Kg/cm², Bar, mBar, PSI, mH₂O, mmH₂O, cmH₂O, inH₂O, ftH₂O, mmHg, inHg, Atm, MPa, kPa, PaCurrent measurement: Active loop: 50 mA, Passive loop: 25 mA, Load resistance: 800 ΩVoltage measurement: 0 to 30 VDCResolution (mA / V): 0.001Switch test: Maximum 5 VDCMedium: AirOverpressure alarm: Visual and audible, 120% FSPressure generation: Integrated pneumatic pump with fine adjustment vernier and depressurization valvePower supply: Rechargeable 7.2 V AA batteryDimensions / Weight: 330 x 235 x 125 mm, 4 kg
CN-MT Blackbody Calibration Oven 250 °C to 600 °C
CN-BT (Low Temperature):
- Temperature Range: Ambient Temp. +10 °C to 350 °C
- Accuracy: Less than 0.5% F.S. (Min. 1 °C)
- Stability: ± 0.5 °C
- Resolution: 0.1 °C
- Emissivity: 0.98
- Aperture Diameter: 25 mm
- Time to Reach Max Temperature: 45 minutes
- Stabilization Time: 20 minutes (above 75 °C)
- Dimensions (L x W x H) / Weight: 485 x 430 x 190 mm / 11 kg
- Calibration Certification: Factory with ISO17025 traceability included
PI105 Digital pressure gauge ± 0,05 %
- Accuracy: ± 0.05% of full scale
- Units: kPa, Pa, PSI, Kg / cm², Bar, MPa
- Display: Large LCD screen with 5 DIGIT dual display
- Keys: On / Off, Reset, backlight
- Connection: 1/2" G
- Dial size: 105 mm
- Pressure and temperature display simultaneously
- Max & min pressure recording
- Battery alarm function
- Ease of use, robust design and reliable performance
- Lithium battery 1 year autonomy in 24 hour operation
- Delivered in a storage case
- Calibration certificate with factory traceability
- ISO17025 certificate COFRAC equivalent or NIST optional
PRCAL 516 Multifunction Temperature Calibrator
- Generation and measurement of electrical signals
- Generation and measurement of temperatures
- Pulse frequency generation and measurement
- Automatic switch test
- 24 V loop power supply
- RS-232 communication
- Data recording
- Documentation and automated procedures
PPC-H 400 Hydraulic pressure calibrator 0 to 400 Bar ± 0.05%
Models: PPC-H (accuracy 0.05% FS)
Pressure Range: 0 to 400 Bar.Temperature Compensation: 0 °C to 50 °C.
Display: Backlit LCD, 5-digit resolution, multiple units (Pa, Bar, PSI, mmHg, etc.).
Inputs: Current (50 mA active / 25 mA passive), voltage (0-30 VDC), resolution 0.001.
Pressure Generation: Integrated pneumatic/hydraulic pumps with fine adjustment.
Construction: Robust IP10 case, 330 x 235 x 125 mm, 6 kg.
Overpressure Alarm: 120% FS (visual/audible).
Power Supply: Rechargeable battery.
Delivery: Calibrator, adapters, test kit, oil, RS-232, manual.
PPC-P-10 Portable pressure calibrator (-)0,85 to 2 Bar ± 0,05%...
Pressure range: -0.85 to 10 barPressure measurement and generationAccuracy: ± 0.05% FSTemperature compensation: 0 °C to 50 °CSelectable measurement units:Kg/cm², Bar, mBar, PSI, mH₂O, mmH₂O, cmH₂O, inH₂O, ftH₂O, mmHg, inHg, Atm, MPa, kPa, PaCurrent measurement: Active loop: 50 mA, Passive loop: 25 mA, Load resistance: 800 ΩVoltage measurement: 0 to 30 VDCResolution (mA / V): 0.001Switch test: Maximum 5 VDCMedium: AirOverpressure alarm: Visual and audible, 120% FSPressure generation: Integrated pneumatic pump with fine adjustment vernier and depressurization valvePower supply: Rechargeable 7.2 V AA batteryDimensions / Weight: 330 x 235 x 125 mm, 4 kg
